Description

Sunsynk 8kW Compact Combo with Double BSLBat Neuro 5 5.12kWh Batteries

This Solis solar combination is ideally suited to a 4/5 bedroom house.

This combination includes:

1. Sunsynk 8kW Compact Inverter (Incl Wifi) Single Phase
2. 2x BSLBat Neuro 5 5.12kwh Lithium-Ion Battery
3. 8 x Tier 1 x 600W Solar Panels
4. ALL Mounting Structure Included
5. ALL Switchgear and Combiner Boxes Included
6. ALL Cables and Connectors Included

Free Delivery

Product Description

This system combines a high-capacity hybrid solar inverter with modular energy storage to deliver reliable renewable energy management and backup power. The inverter integrates solar panels, grid power and batteries, automatically switching between sources and enabling grid-tie, off-grid, or backup operation. The paired BSLBatt Neuro 5 batteries are advanced LiFePO4 wall-mount units with a 5.12 kWh nominal capacity each, designed for long life and scalable expansion. Together, the inverter and batteries offer a scalable and robust solar energy system suitable for reducing grid dependency, maximising self-consumption, and supporting essential loads during outages.

---

Technical Specifications

Inverter (Sunsynk 8 kW Compact Hybrid)

• Rated power: 8000 W continuous output.

• DC input maximum: 12 800 W.

• MPPT trackers: Dual MPPT for optimized solar input.

• MPPT voltage range: Minimum ~125 V to maximum ~425 V.

• DC startup/shutdown voltage: ~150 V.

• Max DC current: ~52 A.

• Max AC output power (5 min): ~8800 W.

• Surge AC power (1 s): ~12 000 W.

• Efficiency: Approx. 96.5 % Euro efficiency.

• Integrated DC switch: Yes.

• Communication: Wi-Fi logging, app monitoring supported.

• Warranty: Standard 5 years.

• Protection rating: IP65 for outdoor/indoor installation.

Battery Modules (BSLBatt Neuro 5 × 5.12 kWh each)

• Nominal voltage: 51.2 V DC.

• Nominal capacity: 100 Ah per unit.

• Nominal energy: 5.12 kWh per unit.

• Chemistry: Lithium Iron Phosphate (LiFePO4).

• Maximum continuous discharge current: ~100 A.

• Peak discharge current: ~200 A (short bursts).

• Maximum continuous charge current: ~100 A.

• Integrated BMS protections: over-charge, over-discharge, over-current, temperature and short-circuit protections.

• Communication: RS232, RS485 and CAN bus.

• Cycle life: >4000 cycles typical (dependent on DoD).

• Installation type: Wall-mount or floor with modular expansion up to many units in parallel.

• Operating temperatures: Charge 0 °C to 55 °C; Discharge -20 °C to 55 °C.

• Warranty: Approx. 10 years.

Disclaimer: Please ensure a certified installer commissions the combo. Minor adjustments may be required in terms of voltage, current, cable lengths and other connected appliances drawing power.
