Deye 5kW Residential Combo with Deye SE-F5 Plus 5kWh Battery

This Deye solar combination is ideally suited to a 3 bedroom house

This combination includes:

1. Deye 5kW Inverter (Incl Wifi) Single Phase
2. Deye SE-F5 Plus 5kwh Lithium-Ion Battery
3. 6 x Tier 1 x 400W Solar Panels
4. ALL Mounting Structure Included
5. ALL Switchgear and Combiner Boxes Included
6. ALL Cables and Connectors Included

Free Delivery

Product Description

This residential combo pairs a Deye 5kW hybrid inverter with the Deye SE F5 5kWh LiFePO4 battery to deliver a reliable and scalable solar energy system. The inverter intelligently manages power from solar panels, the grid, and battery storage, allowing operation in grid tied, off grid, or backup modes. It features advanced MPPT technology to maximize solar harvesting and supports lithium battery communication for efficient charge and discharge control.

The Deye SE F5 battery provides 5kWh of nominal energy storage using lithium iron phosphate chemistry, known for safety, long cycle life, and thermal stability. The system is suitable for powering essential household loads during outages, reducing electricity bills, and increasing energy independence. Additional batteries can be added for expanded storage capacity.

Technical Specifications

Inverter Deye 5kW Hybrid Single Phase

• Rated AC output power 5000W

• Maximum AC output power approximately 5500W

• AC output voltage 220V to 230V single phase

• Output frequency 50Hz or 60Hz

• Maximum PV input power approximately 6500W

• MPPT trackers 2

• MPPT voltage range approximately 125V to 425V DC

• Maximum PV input voltage 500V DC

• Battery voltage range 40V to 60V DC

• Maximum charge and discharge current up to 120A

• Peak off grid power up to 2 times rated power for short duration

• Maximum efficiency approximately 97 percent

• MPPT efficiency greater than 99 percent

• Protection features DC reverse polarity protection, AC overcurrent protection, short circuit protection, anti islanding protection, over temperature protection

• Communication interfaces CAN and RS485

• Monitoring support WiFi or LAN optional

• Cooling intelligent fan cooling

• Protection rating IP65 suitable for indoor and outdoor installation

• Warranty typically 5 years depending on supplier

Battery Deye SE F5 5kWh LiFePO4

• Nominal energy capacity 5.12kWh

• Usable energy approximately 4.6kWh depending on depth of discharge

• Battery chemistry Lithium Iron Phosphate LiFePO4

• Nominal voltage 51.2V

• Nominal capacity 100Ah

• Operating voltage range approximately 44.8V to 57.6V

• Maximum continuous charge current 100A

• Maximum continuous discharge current 100A

• Peak discharge current approximately 120A for short duration

• Recommended depth of discharge up to 90 percent

• Cycle life greater than 6000 cycles at standard conditions

• Scalability supports multiple units in parallel

• Communication CAN and RS485 compatible with Deye inverters

• Operating temperature charging 0C to 55C discharging minus 20C to 55C

• Installation wall mounted or floor standing

• Protection rating IP21 indoor installation

• Warranty typically 5 years with extended options

Disclaimer: Please ensure a certified installer commissions the combo. Minor adjustments may be required in terms of voltage, current, cable lengths and other connected appliances drawing power.
