Description

Luxpower 15kw Supersized Combo.

This Luxpower solar combination is ideally suited to a 10 bedroom house or commercial space.

This combination includes:

1. Luxpower 15kw Trip LV Inverter (Incl Wifi) Single Phase
2. Hina PowerGem Max 16kwh Lithium-Ion Battery
3. 20 x Tier 1 x 600W Solar Panels
4. ALL Mounting Structure Included
5. ALL Switchgear and Combiner Boxes Included
6. ALL Cables and Connectors Included

Free Delivery

Product Description

This Supersized Combo combines a 15kW range LuxPower hybrid inverter with a 16.076kWh Hina ESS PowerGem Max battery to deliver powerful solar energy conversion and high capacity storage in one integrated solution. The hybrid inverter manages solar panel input, battery charging and discharging, mains interaction, and backup power distribution, making it suitable for extended autonomy and load support during grid outages.

The Hina ESS PowerGem Max 16kWh battery module uses advanced lithium iron phosphate chemistry for high safety, long cycle life, and liberal usable energy. An intelligent battery management system (BMS) includes multi layer protections and active cell balancing to protect against common fault conditions. The battery supports multiple installation options and can be scaled in parallel with additional units, allowing for future capacity expansion.

This combo is ideal for homes or businesses with higher power demands, offering energy cost reduction through self consumption, peak load support, and dependable backup when utility power is unavailable.

---

Technical Specifications

Inverter Specifications (LuxPower 15kW Hybrid Inverter)

• Rated output power 15000W

• Hybrid functionality manages solar input, battery charge/discharge, and grid interaction

• Suitable for residential and commercial solar energy systems

• Multiple MPPT solar inputs supported (exact specs depend on specific LuxPower model)

• Built in communication interfaces including CAN and RS485 for battery integration

• Supports parallel expansion of multiple inverters for larger systems

• Protection features including overcurrent, overvoltage, short circuit and over temperature safeguards

• Typically supplied with installation accessories and monitoring options

• Qualified and certified for solar hybrid energy systems

Battery Specifications (Hina ESS PowerGem Max 16kWh)

• Cell type Lithium iron phosphate LFP

• Rated energy 16.076kWh with approximately 90 percent usable capacity

• Rated voltage 51.2V

• Rated capacity 314Ah

• Charge voltage approximately 57.2V DC

• Cycle life up to 8000 cycles at typical depth of discharge

• Depth of discharge approximately 90 percent

Battery Power and Current

• Continuous charge current around 160A

• Continuous discharge current around 200A

• Peak discharge current up to 220A for short bursts

• Parallel expansion supported up to 32 to 35 units without extra devices

Protection and Safety

• Integrated smart Battery Management System (BMS)

• Overcharge and over discharge protection

• Overcurrent and short circuit protection

• Temperature protection and reverse connection protection

• Built in fire suppression system for enhanced safety

• Active cell balancing

• Certified CE, UN38.3, IEC62619 safety standards

Mechanical and Environmental

• Battery dimensions approximately 900 × 445 × 230 mm

• Weight approximately 120 kg

• Protection rating typically IP20 for indoor installation

• Operating temperature range typically -20°C to +55°C

• Suitable for wall mounted, floor standing, or stackable installation

System Integration and Compatibility

• Battery and inverter communicate via CAN/RS485 interfaces

• Compatible with multiple inverter brands including LuxPower and others

• Designed for both solar backup and hybrid power management

• Ideal for high load demand applications requiring robust storage capacity

Warranty and Lifecycle

• Battery backed by a 10 year warranty with 8000 cycle performance indication

• Inverter warranty and support subject to manufacturer terms

Disclaimer: Please ensure a certified installer commissions the combo. Minor adjustments may be required in terms of voltage, current, cable lengths and other connected appliances drawing power.
