Description

Solis 8kw Hyper Combo.

This Solis solar combination is ideally suited to a 4/5 bedroom house.

This combination includes:

1. Solis 8kW Inverter (Incl Wifi) Single Phase
2. 2x Dyness 5.12kwh Lithium-Ion Battery
3. 8 x Tier 1 x 600W Solar Panels
4. ALL Mounting Structure Included
5. ALL Switchgear and Combiner Boxes Included
6. ALL Cables and Connectors Included

Free Delivery

Product Description

The Solis 8kW Hyper Combo with Double Dyness DL5.0 5.12kWh Batteries combines a high performance Solis 8kW hybrid solar inverter with two Dyness DL5.0 5.12kWh batteries to provide robust solar conversion, energy storage, and backup power in one integrated system. The Solis hybrid inverter manages solar DC input, battery charging and discharging, and load support when utility power is unavailable.

This combo is designed to maximise self consumption of solar energy, reduce utility costs, and provide dependable backup power for critical household or light commercial loads. The Dyness DL5.0 batteries use advanced lithium iron phosphate chemistry for enhanced safety, long cycle life, and stable performance. With two battery units connected in parallel, total usable storage capacity is approximately 10.24kWh, allowing extended runtime for essential loads.

Ideal for homes and small businesses seeking a high output, efficient solar storage system, this combo supports flexible installation and integration with monitoring tools for real time system tracking.

---

Technical Specifications

Inverter Specifications (Solis 8kW Hybrid Inverter)

• Rated output power 8000W

• Pure sine wave AC output

• Hybrid inverter managing solar input, battery charging, and grid interaction

• Dual MPPT solar input channels for flexible PV array configuration

• Built in communication interfaces including CAN and RS485 for battery integration

• Supports parallel operation of multiple inverters for larger systems

• Protection features including overcurrent protection, over voltage protection, short circuit protection, and over temperature protection

• Monitoring support via app or web portal depending on model configuration

• Typically supplied with installation accessories and communication cables

Battery Specifications (Two Dyness DL5.0 5.12kWh Batteries)

• Battery type Lithium iron phosphate LiFePO4

• Nominal energy per unit 5.12kWh

• Total nominal energy 10.24kWh with two units in parallel

• Nominal voltage 51.2V per unit

• Nominal capacity 100Ah per unit

• Recommended depth of discharge up to 90 to 95 percent

• Cycle life greater than 6000 cycles at 80 percent depth of discharge

• Integrated smart battery management system

• Communication interfaces CAN and RS485 for inverter integration

Electrical Parameters

• Inverter supported battery voltage range 44.8V to 57.6V

• Recommended charge/discharge current per battery 50A

• Maximum continuous charge/discharge current per battery 75A to 100A depending on configuration

• Parallel connection of batteries supported for increased capacity

Protection Features

• Overcharge protection

• Over discharge protection

• Overcurrent protection

• Short circuit protection

• Over temperature protection

• Cell balancing management

Mechanical Specifications

• Inverter and batteries designed for indoor installation

• Protection rating typically IP20

• Wall mounted or rack mount installation supported for batteries

• Structured cable access for cleaner wiring

Environmental Conditions

• Operating temperature charge 0C to 55C

• Operating temperature discharge -20C to 55C

• Storage temperature -20C to 60C

• Recommended relative humidity 5 to 95 percent non condensing

System Integration and Features

• Compatible with standard solar panel arrays to support MPPT tracking

• Supports battery expansion with additional Dyness units for greater storage capacity

• Monitoring and control via inverter supported app or web interface

• Ideal for solar self consumption, backup power, and load shifting applications

Warranty

• Inverter warranty varies by supplier and manufacturer terms

• Battery warranty typically up to 10 years subject to installation conditions

Disclaimer: Please ensure a certified installer commissions the combo. Minor adjustments may be required in terms of voltage, current, cable lengths and other connected appliances drawing power.
