Description

Product Description

The Huawei SUN2000-25KTL-M5 string inverter is designed for efficient DC-to-AC conversion in medium- to large-scale solar installations. It supports up to 37.5 kW of PV input power with a wide MPPT operating range and dual independent trackers for optimal energy harvesting under varied site conditions. Built-in protections include arc fault detection, anti-islanding protection, DC/AC surge protection, residual current monitoring, and PID recovery, enhancing safety and reliability. The inverter’s IP66 weather-resistant enclosure and smart air cooling enable long-term outdoor operation. Integrated communication interfaces and compatibility with Huawei’s FusionSolar platform allow remote monitoring, diagnostics, and performance optimisation to improve uptime and system performance.

---

Technical Specifications (Bullet Form)

General

• Model: SUN2000-25KTL-M5

• Inverter type: Three-phase grid-tied string inverter

• Rated AC active power: 25 000 W

• Maximum AC apparent power: 27 500 VA

• Protection class: IP66 (dust and water resistant)

• Cooling: Smart air cooling

• Operating temperature range: -25 °C to +60 °C

• Dimensions (W × H × D): 546 × 460 × 228 mm

• Weight: 21 kg

Efficiency

• Maximum conversion efficiency: 98.4 %

• European weighted efficiency: ~98.2 %

DC (PV) Input

• Maximum DC input power: 37 500 W

• Maximum DC input voltage: 1100 V

• MPPT operating voltage range: 200 – 1000 V

• Full-load MPPT voltage range: ~530 – 800 V

• Start-up voltage: 200 V

• Rated input voltage: 600 V

• Number of MPPT trackers: 2

• Maximum DC inputs: 4

• Max. input current per MPPT: 30 A (two strings) / 20 A (single string)

• Max. short-circuit current: 40 A

AC Output

• Grid connection: Three-phase

• Nominal AC voltage: 220/380 V, 230/400 V, 239.6/415 V

• Rated grid frequency: 50 Hz / 60 Hz

• Maximum output current: 42 A @ 380 V / 39.9 A @ 400 V / 38.5 A @ 415 V

• Adjustable power factor: 0.8 leading to 0.8 lagging

• Total harmonic distortion (THD): ≤ 3 %

Safety & Protection

• AI-assisted arc fault protection (AFCI)

• Input-side disconnection device

• Anti-islanding protection

• AC over-current protection

• DC reverse-polarity protection

• String fault detection

• DC surge protection (Type II)

• AC surge protection (Class II)

• Residual current monitoring unit (RCMU)

• PID recovery function integrated

Communication & Monitoring

• Built-in RS485 communication

• Optional communication: WLAN/Ethernet/4G via Smart Dongle

• Compatible with Huawei FusionSolar monitoring platform
