Description

Product Description

• High-voltage LFP battery using lithium iron phosphate chemistry for enhanced thermal stability and long cycle life.

• Nominal usable energy of 10 kWh with a scalable modular design (modules stackable and extendable).

• Compact and plug-and-play form factor with CAN communication simplifies installation and system integration.

• Designed for seamless compatibility with high-voltage hybrid inverters, enabling self-consumption optimisation, time-of-use shifting, and backup support.

• IP55 protection rating and passive cooling allow safe use in indoor or outdoor locations with environmental resistance.

• Includes comprehensive protections and battery management via integrated BMS for over/under voltage, overcurrent, and thermal events.

Technical Specifications

General

• Battery type: Lithium iron phosphate (LiFePO₄) prismatic cells with integrated BMS.

• Usable energy capacity: 10.0 kWh.

• Nominal system voltage: 140.8 V.

• Operating voltage range: 118.8 – 160.6 V.

• Continuous charge/discharge current: 50 A.

• Maximum depth of discharge (DOD): Up to 100 % (configurable).

Performance & Lifespan

• High cycle life with LFP chemistry and advanced protection design (typically > 6,000 cycles at full DOD).

• High usable energy ratio due to wide DOD and efficient BMS control.

Communication & Integration

• Communication interface: CAN for integration with compatible inverters and monitoring platforms.

• Compatible with Sungrow high-voltage hybrid inverter systems for coordinated charging/discharging and system monitoring.

Protections & Safety

• Over/under voltage protection.

• Overcurrent protection.

• Over/under temperature protection.

• Short circuit protection.

• Protective enclosure: IP55 rated for dust and water resistance.

Environment & Physical

• Cooling: Natural convection (passive cooling).

• Operating temperature (charge): 0 °C to 50 °C; (discharge): –20 °C to 50 °C.

• Dimensions (approx): 675 × 580 × 350 mm.

• Weight (approx): 106 kg.

• Installation method: Upright indoor/outdoor floor-mounted setup.

Certifications & Warranty

• Certified to IEC and UN standards for safety and transport (e.g., IEC 62619, UN38.3) – certifications typical for the series.

• Standard industry warranty (often 10 years depending on region and supplier)
