Product Description

The Freedom Won LiTE Home 15/12 Battery is engineered to meet the energy storage needs of homes and small commercial installations where space efficiency and reliability are essential. Built using high-quality LiFePO₄ cells and an integrated Battery Management System (BMS), the battery ensures stable performance and advanced protection throughout its lifespan. Operating on a 52 V nominal system, it is fully compatible with most 48 V hybrid, grid-tied, and off-grid inverters. The intelligent BMS continuously monitors cell voltage, current, temperature, and state of charge to prevent overcurrent, over-voltage, under-voltage, and thermal issues. A shunt-trip circuit breaker allows safe isolation during fault conditions. Encased in a durable aluminium enclosure, the LiTE Home 15/12 is suitable for indoor or protected installations and is backed by Freedom Won’s strong local support and warranty.

Technical Specifications (Bullet Form)

Capacity & Energy

Total nominal energy capacity: 15 kWh

Usable energy at 80 percent DoD: 12 kWh

Usable energy at 90 percent DoD: 13.5 kWh

Voltage & Compatibility

Nominal voltage: 52 V DC

Designed for 48 V inverter systems

Typical operating voltage range: approximately 47 – 56 V

Current & Power

Maximum continuous discharge power: 15 kW

Maximum continuous discharge current: 300 A

Maximum peak discharge current: up to 375 A

Maximum continuous charge power: 15 kW

Maximum continuous charge current: 300 A

Recommended maximum inverter size: up to ~10 kVA

Battery Technology

Cell chemistry: Lithium Iron Phosphate (LiFePO₄)

High cycle life with excellent thermal stability

Battery Management & Protection

Integrated Battery Management System (BMS)

Protection against overcurrent, over-voltage, under-voltage, over-temperature, and weak cells

Minimum state-of-charge protection

Shunt-trip circuit breaker with manual reset

Communication & Interfaces

CAN Bus communication for compatible inverters

RJ45 communication port

USB interface for configuration and diagnostics

Physical Specifications

Enclosure: Powder-coated aluminium

Installation: Indoor or fully protected environment

Approximate dimensions (H × W × D): ~900 × 490 × 290 mm

Approximate weight: ~140 kg

Ingress protection: Typically IP20

Warranty & Lifespan

Standard warranty: 10 years or up to 4 000 cycles at 80 percent DoD

Expected service life: 15+ years under normal residential use

Applications

Residential solar energy storage

Hybrid and off-grid systems

Backup power for essential household loads
